Availability: 7 in stock
EAGTAC adopts current regulated high efficiency circuit to manage current that goes through the LED.
Maximum 100+ hours runtime
P20C2 MKII runs for 100 (and up) hours on its lowest brightness level. The current regulated and non-PWM dimming circuit design allows constant and non-flashing output throughout its runtime for all output levels.
At turbo mode (highest brightness level), P20C2 MKII current regulates for 1.5 hours using two EAGTAC CR123A batteries (XM-L2 version runs for 1.2 hours at turbo due to higher output current).
C2100 V circuit
We use current regulation method to control the amount of current going through the LED for all output levels. This results in constant brightness output regardless of battery type, LED model, and temperature/voltage change.
The XP-G S2 version uses C1500 V circuit, which essentially shares the same design, but with lower current to best suit the XP-G LED requirement.
Green design
We only use RoHS compliant and lead-free components to build our circuits and products.
We also work hard to offer environmentally friendly green packaging (such as smaller package for lower transit cost, recyclable PET label/container, and eco-friendly cardboard outer package).
High lumen output
LED lumen
XM-L2 U2: 8501-636/126/10
XP-G2 R5: 5301-397/113/10
ANSI FL-12 lumen
XM-L2 U2: 6221-470/101/8
XP-G2 R5: 3861-315/89/8
Turbo boost technology
1) Turbo boost technology is activated every time you turn on at turbo output setting for maximum brightness. It lasts for three minutes and then it reduces its regulated output by 20% to prolong runtime.
2) ANSI FL-1 Lumens is a measurement of light output standardized by American National Standards Institute for use with flashlights. This ANSI Lumen measurement is the total overall light output being emitted from the flashlight. This measurement is generally more accurate as it takes into consideration the loss from reflector/lens/bezel. EAGTACs ANSI Lumen output is measured using a calibrated integrated sphere three minutes after turning on the flashlight.
CREE XM-L2 U2 LED
Cool White output
This gives you the maximum brightness output in its class. Our XM-L2 U2 LED offers 850 LED lumen at turbo mode with industrial leading efficiency (175+ lumen/watt at general mode).
Neutral White output
If you need awesome beam output out in the woods, or areas with a lot of green vegetation, use our neutral white LED as it offers higher CRI (Color rendering index) compared to cool white LED. Neutral white LED renders color like the sun in the afternoon. Neutral white LED is approximately 7% dimmer than our top binned cool white LED, but it’s well worth the ability to see the real color of your surrounding.
Color tint selection
Cool White LED
This allows you to view the object with maximum brightness output and gives you maximum beam distance.
Neutral White LED
This gives you better color rendition and more accurate color relative to cool white LED.
Beam distance
The P20C2 MKII reflector design allows you to view object up to – yards/- meters at turbo output with XP-G S2 LED. The XM-L2 U2 LED verion offers 175 yards/160 meters beam distance.
Reflector
P20C2 MKII uses polished aluminum reflector with super low textured reflector for maximum output and a pleasing beam.
